All-in-one Touch Terminal PT-6215

  • 6215back
  • 6215front
  • slider
  • 6215sideback
http://wowslider.com/ by WOWSlider.com v8.6

Be flexible and independent

The PT-6215 All-in-One POS Touch Terminal is the perfect solution for all kind of businesses. The compact and elegant design fits into every environment installation and is extremely counter space saving. As the PT-6215 is an All-in-one Terminal, it can be easy installed without extra modules, cables etc. It is the perfect POS Terminal for everyone who wants to be independent and flexible.

Product Sheet

Additional Information

Technical Data

CPU Intel Atom N270 @ 1.6GHz/512K L2 cache, Chipset Intel 945GSE + ICH7M, Memory System chips with DDR2 1GB standard support up to 2GB, LCD 15” TFT-LCD, Resolution 1024 x 768, Touch 5-wire resistive touch, LCD Brightness 250 cd/m2 (w/o touch), LAN 10/100/1000Mbps on board Ethernet controller, Storage SATA 3.5“ HDD or optional SATA SSD, I/O ports 4 x COM ports 1 x RJ11 port (+24V) 1 x PS/2 Keyboard port 1 x RJ-45 LAN port 5 x USB ports 1 x DC +12V 1 x VGA port, Operation System WEPOS / POSReady / Windows XP Pro / Windows XP embedded / Windows 7 / Linux, Power Supply AC 100V~240V / DC12V / 12.5A 150 watt power adaptor, Environment Operating Storage Temperature 0~40 °C C -20~60 °C Humidity 15% ~ 80% 15% ~ 80%, Dimension 345 mm (W) x 321 mm (D) x 256 mm (H), Integrated Peripherals 3-Track MSR, 2 x 20 VFD customer display, 80 mm Thermal Epson printer with auto cutter, Options Solid State Drive, Raid , RFID module, WiFi module

Special Features

Elegant, compact and fanless design, 15” TFT-LCD touch screen, Open architecture, Modular design for easy maintenance, Integrated 3-track MSR, 80 mm Epson thermal printer, 2×20 VFD customer display
